The round drip irrigation pipe production line is designed for high-speed and stable manufacturing of round drip irrigation pipes with integrated drippers.
The line integrates automatic dripper screening, precise punching, and intelligent winding, meeting the requirements of modern agricultural irrigation pipe production.
Technical Specifications
Item | Pipe diameter | Pipe thickness | Production speed | Dripper spacing | Number of punched holes | Punching speed |
Round drip irrigation pipe making machine | Φ 12-16-20mm | 0.5-1.5mm | 120-150m/min | 100-1000mm | 2、4 holes | 450-500 times/min |
Main Configuration & Features
High-Speed Dripper Screening and Conveying Device
The production line is equipped with a high-speed dripper screening and conveying device capable of identifying and transporting various types of drippers for Φ12, Φ16 and Φ20 mm drip irrigation pipes.
The system adopts an advanced European rotary conveying mechanism.
The conveying guide rail can automatically adjust its forward and backward position, ensuring stable dripper feeding under high-speed operation.
Features:
● Identification and conveying speed: 450–500 pieces/min
● Suitable for multiple dripper designs
● Stable and continuous dripper supply
Automatic Dripper Conveying and Inserting System
The automatic dripper conveying system ensures accurate and stable delivery of drippers.
Drippers are precisely positioned and firmly integrated with the inner wall of the drip irrigation pipe, supporting consistent water distribution during operation.
Features:
● Precise dripper positioning
● Stable integration with pipe inner wall
● Reliable operation at high line speed
Servo-Controlled Punching Device
The punching unit adopts a servo-controlled punching system equipped with two punching machines.
This configuration ensures high accuracy and stability during the drilling process.
Punching number and hole position can be adjusted according to different pipe specifications and irrigation requirements.
Features:
● High punching accuracy
● Stable drilling performance
● Flexible configuration
Automatic Winding System
The winding system consists of a dual-station reel, large swing rotation device, wire arrangement unit, and stable supporting frame.
The system automatically determines winding spacing and roll length based on pipe diameter.
Winding speed and tension are automatically adjusted during production, ensuring uniform and stable coiling.
Features:
● Dual-station automatic winding
● Stable tension control
● Consistent roll quality
Applications
This cylindrical drip irrigation pipe production line is suitable for manufacturing drip irrigation pipes used in:
● Agricultural irrigation systems
● Greenhouse irrigation
● Water-saving irrigation projects
● Large-scale farming applications
Production Line Advantages
● High-speed and stable production performance
● Flexible configuration for different pipe diameters
● High automation level with reduced manual operation
● Suitable for continuous industrial production
